All In One Vertical Stackable Home Battery Storage System With 5kWh LiFePO4 Lithium Battery

Brand Name : Vbrite

Model Number : VB-10KW-Vertical

Place of Origin : China

Name : Home Battery Storage System

Battery Voltage : 40V~58.4V

Storage Capacity : 10240Wh

Weight : 149.4kg

BMS Control : Control Battery Performance

LED Power Display : Traffic Light Display

MOQ : 10PCS

Packaging Details : Carton Packing

Delivery Time : 10~15Day

Payment Terms : L/C,T/T,D/A,D/P,Western Union

Contact Now

All-in-One Vertical Stackable Solar Storage System with 5kWh LiFePO4 Lithium Battery for Smart, Expandable Home Energy Solutions

Specification

Model
VB-10KW-Vertical
Battery Voltage
 40V~58.4V
Storage Capacity
10240Wh
Weight
149.4kg
Type of battery LFE
Capacity 102Ah
Battery Cycle Life 6000
Modular structure 1P16S*2
Capacity for assembled cell discharging by 0.2C
≥100Ah
Standard Charge Condition
Charge with 0.5C constant current and 58.4Vconstant voltage,
charge to 58.4V,continue charging till current declineto ≤0.01C
Internal Resistance
≤80mΩ Assemblage Impedance
Cycle Life
≥6000@25℃,80%EOL
Recommend Charging Temperature
0℃～50℃
Humidity
0-90%
Maximum Altitude
3000m
Parallel Capability
Up to 6 units
LED Power Display
Traffic Light Display
BMS Control
Control Battery Performance

Features:

• Support to expand the battery capacity
• Built-in BMS
• RS485 / RS232 / CAN
• Battery cycles>6000 times
• Support AC / DC priority output

Cautions

• Do NOT expose the battery to water.
• Do NOT expose the battery to re & high temperature.
• Do NOT short circuit, crush or disassemble.
• Make sure the inverter's setting matches with the battery's charge & discharge characteristic.
• Store at 50% capacity, and recharge the battery every 3 months.
• The storage area should be clean, cool, dry and ventilated.
• Disconnect the battery from the inverter and shut down the BMS when the battery is in storage status.
